SIM800L GSM/GPRS Module
—The SIM800L is a 2G GSM/GPRS module that lets a project send SMS messages and make data connections over a mobile network using a standard SIM card.
Specifications
- Quad-band GSM 850/900/1800/1900MHz
- SMS, voice and GPRS data
- Micro-SIM socket
- 3.4-4.4V supply with high peak current (2A bursts)
- Serial AT command interface
- Antenna connector
What you can build with the SIM800L GSM/GPRS Module
- SMS alerts from remote sensors
- Gate and pump control by text message
- Fallback alerting where there is no Wi-Fi
- Simple asset tracking with a GPS module
Compatibility
Works with Arduino, ESP32 and Raspberry Pi over serial AT commands. Important for New Zealand: the 2G networks here have been shut down, so a SIM800L will not connect on local carriers — choose a 4G module such as the SIM7600 instead. Listed for export and legacy projects.
Shipping
Dispatched from New Zealand with courier delivery nationwide, including rural addresses. Prices are in New Zealand dollars.
Availability: Sold out
