Keyes 18B20 Temperature
—A Keyes module built around the DS18B20 digital temperature sensor, which reports calibrated temperature over a 1-Wire bus — several sensors can share a single pin.
Specifications
- DS18B20 1-Wire digital temperature sensor
- Range -55 to 125 °C, ±0.5 °C typical between -10 and 85 °C
- Multiple sensors addressable on one data pin
- Supply 3.3–5 V DC
- 9–12 bit selectable resolution
What you can build with the Keyes 18B20 Temperature
- Multi-point temperature logging
- Brewing, sous-vide and fermentation monitoring
- Heating and hot-water control
- Aquarium and greenhouse monitoring
Compatibility
Arduino, Raspberry Pi and ESP32 using the standard 1-Wire/DallasTemperature libraries.
Shipping
Dispatched from New Zealand with courier delivery nationwide, including rural addresses. Prices are in New Zealand dollars.
Reference: SKU-KT18-264
In stock: 4 Items
